嵌入式项目如何实现应用和硬件分层管理

编排 | 嵌入式大杂烩

来源：
https://blog.csdn.net/ziqi5543/article/details/101512722

一、前言

二、实现原理

三、代码实现

*
    驱动注册
*/
int cola_device_register(cola_device_t *dev);
*
    驱动查找
*/
cola_device_t *cola_device_find(const char *name);
*
    驱动读
*/
int cola_device_read(cola_device_t *dev,  int pos, void *buffer, int size);
*
    驱动写
*/
int cola_device_write(cola_device_t *dev, int pos, const void *buffer, int size);
*
    驱动控制
*/
int cola_device_ctrl(cola_device_t *dev,  int cmd, void *arg);;

头文件cola_device.h：

#ifndef _COLA_DEVICE_H_
#define _COLA_DEVICE_H_


enum LED_state
{
    LED_OFF,
    LED_ON,
    LED_TOGGLE,

};

typedef struct cola_device  cola_device_t;

struct cola_device_ops
{
    int  (*init)   (cola_device_t *dev);
    int  (*open)   (cola_device_t *dev, int oflag);
    int  (*close)  (cola_device_t *dev);
    int  (*read)   (cola_device_t *dev, int pos, void *buffer, int size);
    int  (*write)  (cola_device_t *dev, int pos, const void *buffer, int size);
    int  (*control)(cola_device_t *dev, int cmd, void *args);

};

struct cola_device
{
    const char * name;
    struct cola_device_ops *dops;
    struct cola_device *next;
};

*
    驱动注册
*/
int cola_device_register(cola_device_t *dev);
*
    驱动查找
*/
cola_device_t *cola_device_find(const char *name);
*
    驱动读
*/
int cola_device_read(cola_device_t *dev,  int pos, void *buffer, int size);
*
    驱动写
*/
int cola_device_write(cola_device_t *dev, int pos, const void *buffer, int size);
*
    驱动控制
*/
int cola_device_ctrl(cola_device_t *dev,  int cmd, void *arg);

#endif

源文件cola_device.c：

#include cola_device.h"
#include <string.h>
#include <stdbool.h>


struct cola_device *device_list = NULL;

*
    查找任务是否存在
*/
static bool cola_device_is_exists( cola_device_t *dev )
{
    cola_device_t* cur = device_list;
    while( cur != NULL )
    {
        if( strcmp(cur->name,dev->name)==0)
        {
            return true;
        }
        cur = cur->next;
    }
    return false;
}


static int device_list_inster(cola_device_t *dev)
{
    cola_device_t *cur = device_list;
    if(NULL == device_list)
    {
        device_list = dev;
        dev->next   = NULL;
    }
    else
    {
        while(NULL != cur->next)
        {
            cur = cur->next;
        }
        cur->next = dev;
        dev->next = NULL;
    }
    return 1;
}

*
    驱动注册
*/
int cola_device_register(cola_device_t *dev)
{
    if((NULL == dev) || (cola_device_is_exists(dev)))
    {
        return 0;
    }

    if((NULL == dev->name) ||  (NULL == dev->dops))
    {
        return 0;
    }
    return device_list_inster(dev);

}
*
    驱动查找
*/
cola_device_t *cola_device_find(const char *name)
{
    cola_device_t* cur = device_list;
    while( cur != NULL )
    {
        if( strcmp(cur->name,name)==0)
        {
            return cur;
        }
        cur = cur->next;
    }
    return NULL;
}
*
    驱动读
*/
int cola_device_read(cola_device_t *dev,  int pos, void *buffer, int size)
{
    if(dev)
    {
        if(dev->dops->read)
        {
            return dev->dops->read(dev, pos, buffer, size);
        }
    }
    return 0;
}
*
    驱动写
*/
int cola_device_write(cola_device_t *dev, int pos, const void *buffer, int size)
{
    if(dev)
    {
        if(dev->dops->write)
        {
            return dev->dops->write(dev, pos, buffer, size);
        }
    }
    return 0;
}
*
    驱动控制
*/
int cola_device_ctrl(cola_device_t *dev,  int cmd, void *arg)
{
    if(dev)
    {
        if(dev->dops->control)
        {
            return dev->dops->control(dev, cmd, arg);
        }
    }
    return 0;
}

硬件注册方式:以LED为例，初始化接口void led_register(void)，需要在初始化中调用。


#include stm32f0xx.h"
#include led.h"
#include cola_device.h"


#define PORT_GREEN_LED                 GPIOC
#define PIN_GREENLED                   GPIO_Pin_13

* LED亮、灭、变化 */
#define LED_GREEN_OFF                  (PORT_GREEN_LED->BSRR = PIN_GREENLED)
#define LED_GREEN_ON                   (PORT_GREEN_LED->BRR  = PIN_GREENLED)
#define LED_GREEN_TOGGLE               (PORT_GREEN_LED->ODR ^= PIN_GREENLED)


static cola_device_t led_dev;

static void led_gpio_init(void)
{
    GPIO_InitTypeDef GPIO_InitStructure;
    RCC_AHBPeriphClockCmd(RCC_AHBPeriph_GPIOC, ENABLE);
    GPIO_InitStructure.GPIO_Pin = PIN_GREENLED;
    GPIO_InitStructure.GPIO_Mode = GPIO_Mode_OUT;
    GPIO_InitStructure.GPIO_Speed = GPIO_Speed_50MHz;
    GPIO_InitStructure.GPIO_OType = GPIO_OType_PP;
    GPIO_InitStructure.GPIO_PuPd = GPIO_PuPd_NOPULL;
    GPIO_Init(PORT_GREEN_LED, &GPIO_InitStructure);
    LED_GREEN_OFF;
}

static int led_ctrl(cola_device_t *dev, int cmd, void *args)
{
    if(LED_TOGGLE == cmd)
    {
        LED_GREEN_TOGGLE;
    }
    else
    {

    }
    return 1;
}


static struct cola_device_ops ops =
{
    .control = led_ctrl,
};

void led_register(void)
{
    led_gpio_init();
    led_dev.dops = &ops;
    led_dev.name = led";
    cola_device_register(&led_dev);
}

#include <string.h>
#include app.h"
#include config.h"
#include cola_device.h"
#include cola_os.h"

static task_t timer_500ms;
static cola_device_t *app_led_dev;

led每500ms状态改变一次
static void timer_500ms_cb(uint32_t event)
{
    cola_device_ctrl(app_led_dev,LED_TOGGLE,0);
}

void app_init(void)
{
    app_led_dev = cola_device_find(led");
    assert(app_led_dev);
    cola_timer_create(&timer_500ms,timer_500ms_cb);
    cola_timer_start(&timer_500ms,TIMER_ALWAYS,500);
}

四、总结

这样就可以实现软硬件分层了，是不是非常好用！

五、代码下载链接

https://gitee.com/schuck/cola_os
